Big Screen Multi Parameter Patient Monitor

Product Description

Portable VET 12.1-inch big screen Pm-9000a + multi-parameter monitor



Details:



1. The world famous brand module, high precision, standard parameters, reliable quality, stable performance.



2. High brightness high resolution 12.1 inch color TFT LCD display.



3. The body is light and strong, easy to carry.



4. Rotary shuttle operation mode, Bilingual operation interface, easy to learn, easy to use, easy to operate.



5. Ecg display with full lead and seven channels synchronously.



6.ST segment automatic detection, arrhythmia analysis, drug concentration drop table analysis.



7.NIBP double overpressure protection temperature drift control and other technologies to ensure accurate measurement and protect patient safety.



8. Powerful storage capacity, full parameter trend chart chart data, ECG waveform storage and playback, power failure to save data function.



9. The upper and lower limits of alarm can be set arbitrarily, automatic sound and light double alarm.



10. Suitable for cats, dogs and other mammals.



11. Anti-defibrillation, anti-interference of high frequency electroknife.



12. Support wired and wireless networking, support online software upgrade.



13. Optional built-in removable lithium battery, alternating current, dc dual use.



14. Optional built-in dual-channel hot array recorder, real-time printing waveform and icon.



15. It is widely used in all kinds of pet clinics, pet hospitals, veterinary stations and zoos.







Standard configuration: PM-9000A+ pet version of a host, an animal electric clip type cable, a set of animal blood pressure cuff, a set of animal oxygen probe, a set of temperature probe, a power line, a ground wire.



Optional: Built-in rechargeable lithium battery, dual channel thermal printer, monitor cart/stand/hanger.







Technical parameters:



ECG ECG



Lead selection: full lead, ⅰ, ⅱ, ⅲ, aVF, aVR, aVL, V1 -- 6 chest lead display



Gain selection: ×1, ×2, ×0.25, ×0.5 four grades



Frequency: 0.5 Hz - 100 Hz



Common mode signal rejection: greater than 70dB



Scanning speed: 12.5mm/s, 25mm/s, 50mm/s three standard files



Accuracy of heart rate: ±5 beats/min



Calibration signal: 1mV (peak value, accuracy ±3%)



ST segment detection: Measurement range (-2.0mV -- +2.0mV)



Use standard: comply with ANSI/AMI EC13-2002 standard



Response time: 1S



Alarm mode: sound and light alarm



Preset range of heart rate alarm :(alarm over preset value)



The upper limit can be adjusted from 1 to 255 times/min



The lower limit can be adjusted from 0 to 254 times/min







NIBP blood pressure



Technique: oscillographic method



Measurement method: Reverse measurement data is more accurate



Measurement unit: mmHg/Kpa



Overvoltage protection: double safety protection



Measurement time: less than 45S



Cuff pressure range: 0-250mmHg



Accuracy of blood pressure measurement: mean error and standard deviation values specified in ANSI/AAMI SP10-2002



Initial inflation of cuff: 180mmHg (120mmHg for puppies)



Cuff follow-up inflation: original systolic +30mmHg



Blood pressure measurement range and error:



Systolic pressure 60 mmHg to 250 mmHg



The average pressure is 45 mmHg to 235 mmHg



Diastolic pressure 40 mmHg to 220 mmHg



Blood pressure measurement error: ± 1.1kpa (±8mmHg) or ±10% whichever is greater



Response time: 1S



Alarm mode: sound and light alarm



Alarm prediction range and error :(alarm over preset value)



The upper systolic blood pressure ranges from 1mmHg to 255 mmHg



The lower limit ranges from 0 mmHg to 254 mmHg



The upper diastolic blood pressure ranges from 1mmHg to 255 mmHg



The lower limit ranges from 0 mmHg to 254 mmHg



Alarm error: ±1 mmHg



Standard: comply with ANSI/AAMI SP10-2002 standard







SPO2 oxygen saturation



Scope: 0-100%



Accuracy: 1%



Resolution: 1%



Pulse rate: 20-250 beats/min



Response time: 1S



Alarm mode: sound and light alarm



Alarm range and error :(alarm over preset value)



The upper limit is 1% to 100%



The lower limit ranges from 0% to 99%







TEMP temperature



Technology: high sensitivity thermistor probe



Temperature measurement range: 20℃-- 45℃



Resolution: 0.1%



Temperature accuracy: ±1℃



Response time: 1S



Alarm mode: sound and light alarm



Preset alarm range and error :(alarm over preset value)



The upper limit is adjustable between 20.1℃ and 45.5℃



The lower limit can be adjusted between 20℃ and 45.4℃



Alarm error: ±1℃







Breathe RESP



Respiratory rate range: 0-60 breaths/min



Accuracy: + / - 1 RPM



Response time: 1S



Gain selection: ×1, ×2, ×4, ×0.5 four grades



Alarm mode: sound and light alarm



Preset alarm range and error :(alarm over preset value)



The upper limit is adjustable between 10-100 beats/min



The upper limit is adjustable between 0 and 99 beats/min



Alarm error: ±1rpm







Printer (optional)



Specification: Dual channel thermoarray recorder



Printing mode: record waveform and text in real time or triggered by events



Resolution: horizontal: 400dpi/vertical: 800dpi



Note: Date (year/month/day)/Time (24 hours)



Optional wall bracket, mobile bracket, visiting backpack







System



Display: 12.1-inch TFT true color LCD screen



Battery (optional) : LeadAcid fully sealed and maintenance-free battery



Safety standard: LEC601-1 (INTERNATIONAL GB9706.1)
