Class I Hospital Emergency Equipment Ceiling Operating Lamp 80000Lux 160000 lux
Contact Person : JUCCY
Phone Number : 0086-17717698563
WhatsApp : +8617717698563
| Minimum Order Quantity : | 1pc | Price : | $400.00/Sets 1-4 Sets |
|---|---|---|---|
| Packaging Details : | carton package | Delivery Time : | about 5 days |
| Payment Terms : | T/T, Western Union,Payoneer | Supply Ability : | 10000pcs/month |
| Place of Origin: | Guangdong, China | Brand Name: | Lifotronic |
|---|---|---|---|
| Certification: | CE,ISO13485 | Model Number: | CS-20 |
|
Detail Information |
|||
| Type: | Syringe Pump | Instrument Classification: | Class II |
|---|---|---|---|
| Warranty: | 2 Years, 2 Years | After-sale Service: | Online Technical Support |
| Product Name: | Infusion Pump | Flow Rate Range: | 1-600ml/hr |
| Flow Rate Increment: | 1ml/hr | Dose Range: | 1ml -3000ml Or Infinite Dose |
| Dose Increment: | 1ml | Battery: | Lithium Ion, Above 24hr Life @ 125ml/hr |
| Battery Charge Time: | 6 Hrs | Maintenance: | No Annual Maintenance Or Calibration Required |
| Weight: | 676g | ||
Product Description
|
Display range of volume delivered
|
|
|
0.1~9999.9mL (in steps of 0.1 mL,1000 mL/h or above, in steps of 1mL)
|
|
|
|
|
|
|
||||||||
|
Setting of delivery limit
|
|
|
0.1~9999.9mL (in steps of 0.1 mL, 1000 mL/h or above, in steps of 1mL)
|
|
|
|
|
|
|
||||||||
|
Accuracy of flow rate
|
|
|
Accuracy including syringe: within ±2% (Mechanical accuracy: within ±1%)
|
|
|
|
|
|
|
||||||||
|
KVO-Keep vein open rate
|
|
|
0.1~5mL/h adjustable, 1ml/h as default;
|
|
|
|
|
|
|
||||||||
|
Occlusion pressure
|
|
|
0.1~1.2bar, 9 adjustable levels;
|
|
|
|
|
|
|
||||||||
|
Alarms
|
|
|
End of infusion --infusion ends soon / Occlusion/ Plunger or clutch disengaged/ Syringe dislocated/ Low battery--end of battery/
Power cable disconnected/ Non--operation time over/ Flow rate over limit/ Volume complete (a volume limit has been set)/ System error/ Deactivation of KOR rates possible |
|
|
|
|
|
|
||||||||
|
Power supply
|
|
|
AC 110~230V, 50/60Hz;
Inner Lithium battery: DC 11.1V; Continuous operation time of battery: over 6 hours for dual channel when battery is recharged for 12 hours under power off condition |
|
|
|
|
|
|
||||||||
|
Power consumption
|
|
|
20VA
|
|
|
|
|
|
|
||||||||
|
Operation conditions
|
|
|
Ambient temperature: 5~40 ℃ ; Atmospheric pressure: 86~106kPa; Relative humidity: 20%~80%; Non-‐condensable;
|
|
|
|
|
|
|
||||||||
|
Storage and transportation conditions
|
|
|
Ambient temperature: --20~50℃; Relative humidity: 10%~95%; Non--condensable; Atmospheric pressure: 50~106kPa;
|
|
|
|
|
|
|
||||||||
|
Classification
|
|
|
Class II, Type CF
|
|
|
|
|
|
|
||||||||
|
IP-Protection
|
|
|
IP22
|
|
|
|
|
|
|
||||||||
|
Dimension
|
|
|
310×120×130mm (W×H×D)
|
|
|
|
|
|
|
||||||||
|
Maximum weight
|
|
|
Less than 2.5kg
|
|
|
|
|
|
|
||||||||
|
Operation type
|
|
|
Continuous operation
|
|
|
|
|
|
|
||||||||
